ST-24AH | Stonewood Industrial Machinery | Planers

  • Power:
    7.5HP 230V 3PH
  • Description

    The Stonewood ST Series planer represents the entry-level machine that provides a cost-effective solution for many of your planing needs without sacrificing quality. It provides many great features, such as the sectional infeed roller, that make it a popular choice for small to medium-sized furniture and cabinet manufacturers. FEATURES: *Cast iron, precision machined frame.

    *Table manufactured from high quality & rib reinforced cast iron for perfect alignment and maximum rigidity.

    *Table surface is polished for a smooth and accurate feeding eff ect.

    *Helical spiral cutterhead standard. Corrugated (80mm diameter) infeed roller.

    *Solid type outfeed roller with smooth surface (56mm diameter).

    *Two (2) adjustable bed rollers from 0 to 0.040” above table.

    *Pressure bars manufactured from cast iron with tension spring and concentrically mounted to cutterhead for exact tolerance of cutting circle.

    *Chip breaker made from ductile iron with loaded spring and independent sections (1/4” yield).

    *Sections are mounted on a steel shaft just ahead of knife-cutting circle.

  • Specs

    Table area|25″x27-1/4″(635x692mm)

    Cutterhead Diameter|3″ (75mm)

    Cutting circle|3-1/4″ (82.5mm)

    Cutterhead speed|5500 rpm

    Spiral row numbers|6

    Knife insert size|15 x 15 x 2.5mm

    Feed rollers|3″ (75mm)

    Table rollers|2-3/8″ (60mm)

    Range of feed speed|36 ft/min

    Stock thickness range|0.079″-7.874″

    Maximum depth of cut|1/4″ (6.3mm)

    Maximum width of stock|24″ (610mm)

    Cutterhead motor|7.5 HP

    Feed drive motor|1 HP

    Net weight|450 kgs(993lbs)

    Gross weight|500 kgs(1103lbs)

    Packing dimensions|44″x42″x44″
