SBW-5300H | Stonewood Industrial Machinery | Bandsaws

  • Power:
    3HP 220V 3PH
  • Description

    The Stonewood SBW-5300H is a robust bandsaw featuring a quick release blade changing system and a foot pedal brake. FEATURES: *On/off push button with safety key lock

    *Foot brake system

    *Built in micro switch to shut down power on door opening

    *Quick release saw blade changing system

    *Deluxe casting iron hand wheel

    *Large solid and rigid cast iron table, rip fence and heavy duty miter gauge

    *Standard 4” dust port x 2 units

    *Quick table tighten/loosen handle

  • Specs

    Motor|3HP 230V 3PH
    Table Size(LXWXH)|29.6″x20.8″x2″(750 x 530 x 50 mm)
    Cast Iron Wheel Size|21″ (530 mm)
    Cutting Height1|4″(350 mm)
    Max. Cutting Width (w/o fence)|20″ (510 mm)
    Max. Cutting Width (with fence)|18-1/4″(465 mm)
    Saw Blade Length|165″ (4190 mm)
    Saw Blade Width|1/4 ~ 1-3/8″ (6 mm – 35 mm)
    Saw Blade Speed|1370 M/min (4500 FPM)
    Single Speed (820 rpm)
    Table Tilting|45°/20°(CE)
    Table Height|35 -1/2″ (900 mm)
    Dust Chute|4″ x 2 pcs (100mm x 2 pcs)
    Braking System|Foot pedal+Micro switch
    (Electronic Braking Switch System)
    Driving Belt|A type x 2 Grooves
    Cast Iron Fence|1-1/4″(W) x 3-5/8″(H)
    (30(W) x 90(H) mm)
    Sound Rating|63-70 db
    Base Size (LXWXH)|33-1/2″x 21-5/8″x 3-1/8″
    (850 x 550 x 80 mm)
    Machine Size(LXWXH)|39.4″x 28.3″x 78 “
    (1002 x 727 x 1982 mm)
    Packing Size|39.4″x 29.1″x 94.8″
    (1006 x 740 x 2410 mm)
    N.W/G.W.|580 / 678 lbs
    (264 / 308 kgs)
