Description
A step up from the SBW3501D the Stonewood SBW-4300 has a greater capacity and bigger motor to accommodate those more industrial applications. FEATURES: *On/off push button *12″ Cutting hieght
*User-friendly quick-release saw blade changing system
*Cutting height adjusting wheel
*Blade tracking see through window
*Table tilting micro-adjustment mechanism
*Miter gauge for various angle cutting
*Dual speed design for muli-purpose cutting
*Ground cast iron table
*Cast iron wheels *2-4″ ports for better dust control -
Specs
Motor|2HP(1.5KW)
Table Size|17″ X 17″(430 x 430mm) Wheel Size|17″(430mm)
Cutting Height|12″(300mm)
Max. Cutting Width|16-1/4″(410mm)
Max. Cutting (Rip Fence)|14-5/8″(370mm) Saw Blade Length|131-1/2″
Saw Blade Width|3/8″ to 1″(9.5mm to 25.4mm)
Saw Blade Speed|(3300/1600sfpm) (1000/490 m/min)
Table Tilting|Left-10° / Right-45°
Table Height From Ground|37 1/2″ (950mm)
Dust Chute Diameter|4″(100mm) X 2
Machine Size (LXWXH)|32 x 26 x 74″(820 x 670 x 1880mm) Packing Size (LXWXH)|30 x 20 x 80″(770 x 510 x 2040mm) N.W/G.W.|266 / 321 lbs(121 / 146 kgs)
